T5 LED UV Light Tube 395NM

Products Brand：XIUSDHK BRAND

Products Classification：LED UV Lighting Series

Specification Model：5W / 9W / 14W / 18W

Products Description：T5 LED UV tube, LED UV black light lamp tube is widely used for shoe factory line detection, fluorescent painting, black light dance fluorescent parties, KTV bars, theme park haunted houses, escape rooms, Halloween.

For custom non-standard products or to learn more about our products, please contact me.

Send Inquiry

Product Details

【Safety Warning】This product emits UVA ultraviolet light. Do not look directly at the light source with naked eyes. Wear professional UV protective goggles during prolonged operation to prevent long-term direct exposure to skin.

T5 LED UV Tube 395-405NM

Specification Parameter Comparison Table
Specification	300MM	600MM	900MM	1200MM
Product Model	XSD-T5TUBE-5W-T03UV	XSD-T5TUBE-9W-T06UV	XSD-T5TUBE-14W-T09UV	XSD-T5TUBE-18W-T12UV
Wavelength	UVA (395-405NM)	UVA (395-405NM)	UVA (395-405NM)	UVA (395-405NM)
Operating Voltage	AC100-245V	AC100-245V	AC100-245V	AC100-245V
Rated Power	5W	9W	14W	18W
Power Factor	PF ≥0.5	PF ≥0.9	PF ≥0.95	PF ≥0.95
LED Quantity	24PCS SMD LEDs	48PCS SMD LEDs	72PCS SMD LEDs	96PCS SMD LEDs
Overall Dimension	L300W26H30MM	L600W26H30MM	L900W26H30MM	L1200W26H30MM

Application Scope

Industrial Use: UV glue & resin curing, ink printing curing, PCB & metal defect inspection, fluorescent thread detection for textile and shoe factories.

Insect Trapping: Suitable for mosquito & flying insect traps in homes, restaurants, warehouses and factories.

Atmosphere Lighting: Bars, KTVs, parties, stages, Halloween black light decorations, theme park haunted houses, activate fluorescent pigments.

Laboratory Use: UV-related experiments, fluorescent reaction observation and teaching research.
